Sprayer technique

Good sources of information on how agrochemicals should be applied are often found on the agrochemical label.

You may still need to adjust your sprayer to the specific spraying conditions you choose for volume rate, driving speed, nozzles and spray pressure.


Calibration for field crop sprayers

Check driving speed:

1) Half fill the spray tank with water.

2) Mark out 100 m – note time to drive the distance.

3) Driving speed formula: Distance driven (m) x 3.6 / Time (sec) = km/h

Example:If it takes 50 seconds to drive 100 metres then the spraying speed is 7.2 km/hour.

Select nozzle:

Use the calibration disc or formula (nozzle spacing 50 cm):

Example: By aligning 150 l/ha and 7 km/h on the calibration disc the line in the "window" (l/ha) shows that we need a flow of 0.875 l/min.

Then a suitable combination of nozzle size and pressure can be found on the lower half of the calibration disc: ISO 025 at 2,3 bar (or ISO 02 at 3,6 bar).

If using the formula: (7 km/h x 150 l/ha)/1200 = 0.875 l/min

Protecting the environment when spraying

For many years, 7 to 8 km/h [and 4 to 6 km/h in dense crops where canopy penetration is needed] have in general, been considered good practice. It is an option that is still of value for today.

Increasingly, it is recognised that the slower the boom moves then the less the turbulence is around it, and hence, less drift and less disturbance to the quality of spray distribution.

Some important considerations needs to be made before choosing a higher tractor gear:

Side effects from higher speed:
How to deal with the side effects:
1) More turbulence / more wind drift
Bigger droplets or TWIN air assistance
2) More boom movementOften the boom should be readjusted for optimum performance at a higher drivning speed
Droplet sizes

The droplet spectrum
All agricultural nozzles produce a range of drop sizes. This is a useful feature as the crops to be sprayed always present a 3-dimestional target that have contrasting leaf surfaces and angles. Hence, in a crop canopy, for example, finer droplets are likely to be deposited in the top and larger droplets lower down.

Drop sizes are measured in micron. 1 micron = 1/1,000,000 metre.

To describe the median droplet sizes produced from a specific nozzle, the term VMD is used.

VMD = Volume Median Diameter
VMD is the mid-way drop size that is reached when the accumulated volume of smaller drops accounts for 50% of the sprayed liquid leaving the nozzle; half the volume is atomised into droplets smaller – and the other half of the volume is larger - than the VMD.

Wind drift has in the past been regraded as being mostly caused by droplets below 150 micron in diameter.

Calibration for handheld spayers
Spray pressure

Spray pressure influences spraying effectiveness in crops by 3 ways:

  • Pressure influences the spray angle: the higher the pressure the wider the spray angle. If the pressure is too low (below 1,5 bar for flat fans and 3 bar for INJET) the spray angle is not wide enough to ensure full overlap on the boom and optimum liquid distribution.
  • The higher the pressure, the smaller the droplets and the more they are likely to be deposited within the upper canopy of the foliage. These smaller drops are also more sensitive to wind movement.
  • The higher the pressure, then the more: ◦surrounding air is entrained that helps penetration of larger droplets within the canopy ◦air turbulence which may increase under leaf deposit of smaller droplets especially when using low output conventional nozzles

Pressures recommended for field spraying with standard and lowdrift nozzles

  • Pressures of 2 to 3 bar for normal flat fan and lowdrift nozzles can be recommended for most applications.
  • Only for well developed dense canopies where penetration is needed - such as spraying weeds that are concealed at the base of a vigorous crop - the pressure could be increased to 5 bar with larger nozzles (03, 04 and bigger).

Pressures recommended for field spraying with INJET nozzles

  • INJET nozzles require a minimum of 3 bar to have a full spray angle but can be used up to 8 bars
Optimize spray technique

Be prepared to optimize spraying technique “on the go”
Rather compromise on drop size than timing.

In many applications - from fungicide spraying in potatoes to dicotyledonous stage, broad leaf weed herbicide treatments -timing is very critical. Here a delay may often prompt the need for a higher dose or an increased number of applications.

The potential efficacy loss due to an increased droplet size - that offers less drift risk - will be less dramatic, as long as a good liquid distribution is maintained. Hence it is a good idea to have a set of low drift nozzles or INJET nozzles ready on the nozzle holders in case wind speed increases – and is a lot more convenient and safer than returning with a half full spray tank. Because there can be up to 10% difference in flow for new and worn nozzles both sets of nozzles should be calibrated - even if both sets are ISO nozzles.
