ALPHA evo

Type

Selfpropelled

Tank Capacity

1,100 gal. (4,100 ltrs)

Boom Width

90 to 120 ft. (27.5 to 36.5 m)

Boom Types

TWIN FORCE

ALPHA evo

Type

Selfpropelled

Tank Capacity

1,100 gal. (4,100 ltrs)

Boom Width

90 to 120 ft. (27.5 to 36.5 m)

Boom Types

TWIN FORCE

Ergonomics, Visibility and Optimization

Longer spraying days and nights and higher spraying speeds place heavier demands on comfort and easy operation.

ALPHA evo features a fine balance between front and rear and has a low total weight giving an optimal weight/capacity ratio and high performance even under wet field conditions. Also the high ground clearance from 61 in./67 in. gives a flexible usage from low to tall crops as sweet corn and sunflowers.


Optimizes visibility with 3-pillar design

The new large spacious EvoCab II is specifically developed by HARDI with its “3-pillar design”, which provides a new standard for visibility with more than 320° around the sprayer.

The cabin is equipped with a pressurisation system, a dust filtering of fresh air, an aerosol and vapor filtering to protect the driver and fulfill the Class 4 requirements.

The new climate control system has been tested intensively in climate chamber in order to bring highest driver comfort in warmest condition.


FloatRide suspension

By equipping the ALPHA with the optional FloatRide, the standard coil spring suspension is replaced by airbags. This ensures even more boom stability and maintains balance of the ALPHA in strong slope. The chassis’ height will be maintained whatever tank volume.

By allowing for individual wheel movement, the ALPHA provides a maximum comfort, even at high spraying speeds through a wheel travel of 33 mph.


Hydraulic Track width Adjustment

The ALPHA evo EcoDrive with FloatRide suspension can be equipped with Hydraulic Track width Adjustment. This Hydraulic Track width Adjustment axle allows a track width from 88 to 126 in. (depending on tire dimensions).

The driver will set his track width from the cab display and will be ready to drive. This will allow changing track width from the road to the field and from cereal crop to maize, row crop or vegetable with a variation of 1 m between minimum and maximum.


Get the ALPHA evo brochure

See all the information about the ALPHA evo including full specifications, in-depth information and much more!

Download your ALPHA evo brochure

Specifications

Tank1,100 gal. (4,100 ltrs)
Pumps, type - gal/min464/12: 85 gal (540rpm) (321 ltrs)
BoomsTWIN FORCE
Engine Deitz 6 cyl. 245 hp / 180 kW (Stage IV / Tier 4F)Standard
Hydrostatic 4-wheel transmission - 33 mph (53 km/h) EcoDrive Standard
Pneumatic suspension FloatRideStandard
Hydrostatic Steering (includes permanent 4, 2 wheel, & 4 wheel)All
Hydraulic Track Adjustment (HTA) - electronic control 88 in. to 126 in. (2.2 m to 3.2 m)Standard
Turning radius 88 in (2.23 m) track width (middle of chassis)192 in. (4.9 m)
Weight (standard machine, empty)* w/ 120 ft. TWIN FORCE22,308 lbs. (10,118 kg)
Weight, front axle, basis machine in transport (empty)*12,782 lbs (5,797 kg)
Weight , rear axle, basis machine in transport (empty)*9,526 lbs (4,321 kg)
Total length*384 in. (9.75 m)
Total height* 380/90 - R54 w/ 61" drop legs156 in. (3.96 m)
Width with TWIN FORCE 90 to 120 ft. (27.5 to 36.5 m)118 in. (3 m)
Track width HTA axle** (380/90 R54)88 to 126 in. (2.2 to 3.2 m)
Wheel base148 in. (3.76m)
Clearance (380/90 R50 - 320/90 R54)61 in./67 in. (1.55 m/1.7 m)
RinseTank108 gal. (410 ltrs)
Fuel tank85 gal. (320 ltrs)
Filling capacity water215 gpm (800 ltrs)
Filling capacity TurboFiller32 gpm (120 ltrs)

* Dimension and weight are given for ALPHA evo 36 m TWIN FORCE boom - 380/90 R46 tyres and chassis clearance 120 cm
** Minimum track width is wider with wider tyres (depending on axle type)
